Ball valves

Our ball valves product line are ON/OFF service valves, trunnion mounted design, that consistently deliver outstanding sealing performance throughout a wide range of conditions, bore sizes and working pressure, including high corrosive and abrasive fluid environments. Ball valves are designed in accordance with international standard API 6A, API 6D, API 6DSS and API 17D.

Main application:

Emergency Shut Down (ESDV)
Blow Down (BDV)
Motor Operated (MOV)
Topside and Underground Pipelines
HIPPS / Fast closure systems
Severe Sour Service environment
High Pressure
High and Low Temperature
Subsea, including subsea skids (SSIVs, PLEMs, PLETs, Hot Tapping).

SE – Side entry split body ball valve

SE Model is a Side Entry Ball valve, split-body featured, designed to be easily disassembled and reassembled in order to simplify service operations without the need of special tools.

Pressure rating	API 6D: ANSI 150 to 4500 API 6A: API 2,000 to 15,000 psi
Temperature	-100°C to +200°C
Bore sizes	API 6D: 2” to 60” API 6A: 1.13/16” to 11”
End connection	Flanged RF/ RTJ (ASME B16.5/B16.47/API 6A) Butt Welded (ASME B16.25) Hub
Material options	Carbon and low alloy steels, stainless steel, duplex and super duplex steels, CRAs
Actuation	Hydraulic and Pneumatic (double acting and spring return), Electric, Manual

VALVES SPECIFICATION

Main features:

Forged body and closures
Soft seated or Metal Seated with Tungsten Carbide Coating
Floating spring energized seats
Self-relieving seats or double piston effect seats configuration
Double Body seals & Triple stem seals
Fire safe API 6FA – API 607 – ISO 10497
Fugitive emission test according to ISO 15848-1 & ISO 15848-2
Double Block and Bleed option
Anti-blow-out stem
Compact design
Bi-directional sealing
Fast closure
High wear resistance
Materials in accordance to NACE MR 01-75

SE-DBB – Side entry twin type ball valve

SE-DBB Model is a Twin Ball valve with two closure elements in one body, split-body featured, with standard double block and bleed feature.

Pressure rating	API 6D: ANSI 150 to 4500 API 6A: API 2,000 to 15,000 psi
Temperature	-100°C to +200°C
Bore sizes	API 6D: 2” to 24” API 6A: 1.13/16” to 11”
End connection	Flanged RF/ RTJ (ASME B16.5/B16.47/API 6A) Butt Welded (ASME B16.25) Hub
Material options	Carbon and low alloy steels, stainless steel, duplex and super duplex steels, CRAs
Actuation	Hydraulic and Pneumatic (double acting and spring return), Electric, Manual

VALVES SPECIFICATION

Main features:

Forged body and closures
Soft seated or Metal Seated with Tungsten Carbide Coating
Floating spring energized seats
Self-relieving seats combined with double piston effect seats configuration
Double Body seals & Triple stem seals
Fire safe API 6FA – API 607 – ISO 10497
Fugitive emission test according to ISO 15848-1 & ISO 15848-2
Double Block and Bleed
Anti-blow-out stem
Compact design
High wear resistance
Materials in accordance to NACE MR 01-75

TE – Top entry ball valve

TE Model is a Top Entry Ball valve bolted bonnet, designed to be serviced on site without the need of removing the valve from the line.

Pressure rating	API 6D: ANSI 150 to 2500 API 6A: API 2,000 to 15,000 psi
Temperature	-100°C to +200°C
Bore sizes	API 6D: 2” to 60” API 6A: 1.13/16” to 11”
End connection	Flanged RF/ RTJ (ASME B16.5/B16.47/API 6A) Butt Welded (ASME B16.25) Hub
Material options	Carbon and low alloy steels, stainless steel, duplex and super duplex steels, CRAs
Actuation	Carbon and low alloy steels, stainless steel, duplex and super duplex steels, CRAs

VALVES SPECIFICATION

Main features:

Cast body
Soft seated or Metal Seated with Tungsten Carbide Coating
Floating spring energized seats
Self-relieving seats or double piston effect seats configuration
Double Body seals & Triple stem seals
Fire safe API 6FA – API 607 – ISO 10497
Fugitive emission test according to ISO 15848-1 & ISO 15848-2
Double Block and Bleed option
Anti-blow-out stem
Compact design
Bi-directional sealing
Fast closure
High wear resistance
Materials in accordance to NACE MR 01-75

SW – Welded body ball valve

SW Model is a welded body design ball valve with no bolted bonnet or body joints which reduce potential external leakages: these features make the SW valve suitable for oil and gas service in underground pipeline or for sour service in surface pipeline, granting a safe and reliable service.

Pressure rating	API 6D: ANSI 150 to 2500
Temperature	-100°C to +200°C
Bore sizes	API 6D: 2” to 60”
End connection	Flanged RF/ RTJ (ASME B16.5/B16.47) Butt Welded (ASME B16.25)
Material options	Carbon steels, stainless steel
Actuation	Hydraulic and Pneumatic (double acting and spring return), Electric, Manual

VALVES SPECIFICATION

Main features:

Welded body
Soft seated or Metal Seated with Tungsten Carbide Coating
Floating spring energized seats
Self-relieving seats or double piston effect seats configuration
Fire safe API 6FA – API 607 – ISO 10497
Fugitive emission test according to ISO 15848-1 & ISO 15848-2
Double Block and Bleed option
Anti-blow-out stem
Extended stem for underground application
Bi-directional sealing
High wear resistance
Materials in accordance to NACE MR 01-75

SUBSEA BALL VALVES

We have a complete line of subsea ball valves, which can be offered side entry, top entry or twin ball design, for both shallow water and deep-water application up to 3000 meters water depth.

Pressure rating	API 6DSS: ANSI 150 to 2500 API 17D: API 2,000 to 15,000 psi
Temperature	-100°C to +200°C
Bore sizes	API 6DSS: 2” to 48” API 17D: 1.13/16” to 11”
End connection	Flanged RF/ RTJ (ASME B16.5/B16.47/API 6A) Butt Welded (ASME B16.25) Hub
Material options	Carbon and low alloy steels, stainless steel, duplex and super duplex steels, CRAs
Actuation	Hydraulic and Pneumatic (double acting and spring return) with ROV override, manual ROV
